CSJ (WF) Coarse Crusher

Main Uses:
This machine is mainly used in medicine, food, chemical industry, metallurgy, construction and other industries to process hard and difficult-to-crush materials, including plastics, tree roots and so on. It can also be used as supporting equipment for the previous process of micro-crushing processing and has a better crushing effect on materials.

Working Principle:
This machine is of horizontal crushing structure. The material enters the crushing chamber from the feed hopper, and is crushed by impact and shearing of the rotating knife and the fixed knife. Under the action of rotating centrifugal force, the material automatically flows to the outlet. The equipment is made of stainless steel, easy to operate and easy to clean.

Technical Parameters:
Model 80 200 300
Capacity (kg / h) 10-100 30-200 80-500
Feed size (mm) ≤50 ≤100
Crushed granularity(mm) 0.5-20
Spindle speed (r / min) 400
Motor Power (kw) 1.5 3 5.5
Weight (kg) 120 200 250

Dimensions (mm)
(Length × width × height)

600×500×950 700×800×1100 880×900×1250
